Samples of Different Digital Circuits

Digital Stopwatch Circuit



Digital Dice Circuit



A2 to 4 Line Single Bit Decoder



Direction Finder Electronic Circuits



Digital Ping Pong Circuit



References:
http://www.google.com.ph/imgres?imgurl=http%3A%2F%2Fwww.circuitstoday.com%2Fwp-content%2Fuploads%2F2008%2F02%2Fstopwatch1.JPG&imgrefurl=http%3A%2F%2Fwww.circuitstoday.com%2Fcategory%2Fclockingtimecircuits&h=661&w=1300&tbnid=S8tSFw0vDFcZpM%3A&zoom=1&docid=AqxZef_cfTjYMM&ei=owoRVLiBForU8gXnooH4Dw&tbm=isch&ved=0CC4QMygAMAA&iact=rc&uact=3&dur=1286&page=1&start=0&ndsp=9

http://www.google.com.ph/imgres?imgurl=http%3A%2F%2Fwww.circuitstoday.com%2Fwp-content%2Fuploads%2F2009%2F06%2Fdigital-dice-circuit.jpg&imgrefurl=http%3A%2F%2Fwww.circuitstoday.com%2Fdigital-dice-circuit&h=583&w=605&tbnid=cdwGSLmc1AwbBM%3A&zoom=1&docid=56-xxYyLaeCyAM&ei=owoRVLiBForU8gXnooH4Dw&tbm=isch&ved=0CC8QMygBMAE&iact=rc&uact=3&dur=673&page=1&start=0&ndsp=9

http://www.google.com.ph/imgres?imgurl=http%3A%2F%2Fwww.ktclear.in%2Fuploads%2F25(1)Digital%252520Circuit%252520Technologies%252520and%252520Sequential%252520Circuits&imgrefurl=http%3A%2F%2Fwww.ktclear.in%2Fmockanswer%3Fmock_question%3DWhat%2520are%2520decoders%3F%25A0&h=735&w=1531&tbnid=vPAQ0XOLmNNGeM%3A&zoom=1&docid=ecc7DZ2fEPrOrM&ei=owoRVLiBForU8gXnooH4Dw&tbm=isch&ved=0CDIQMygEMAQ&iact=rc&uact=3&dur=673&page=1&start=0&ndsp=9

http://www.google.com.ph/imgres?imgurl=http%3A%2F%2Fwww.geocities.co.jp%2FTechnopolis-Mars%2F3335%2FProjects%2Fcompass%2Fcompass.gif&imgrefurl=http%3A%2F%2Fwww.discovercircuits.com%2FD%2Fdirection.htm&h=750&w=1000&tbnid=z3rB3aalebzQvM%3A&zoom=1&docid=md4vGHxdq2Jg-M&ei=owoRVLiBForU8gXnooH4Dw&tbm=isch&ved=0CDUQMygHMAc&iact=rc&uact=3&dur=514&page=1&start=0&ndsp=9

http://www.next.gr/uploads/303-341acaa462.gif

Astable Multivibrators

Astable Multivibrators

-have no stable state.

-these circuits are more commonly known as oscillators.



A typical astable multivibrator or oscillator may be formed using CMOS gates.



The 555 Timer

               -is an integrated circuit (chip) used in a variety of timer, pulse generation, and oscillator applications.

Pin Names



Astable Operation



Charge period t1 = 0.693(R1+R2) C

Discharge period t2 = 0.693(R2) C

Total period T = t1+t2 = 0.693(R1+R2) C

The operating frequency of the generated square wave is equal to 1/T or in simplified form,

f =       1.44

     (R1 + 2R2)C

The duty cycle is a factor of the resistors,

D =         R2

        R1 + 2R2

Reference:

          Benjo Tirol. Fundamentals of Digital Electronics. Electronics Hobbyists Publishing House.

    https://www.google.com.ph/searchq=astable+output&biw=1366&bih=677&source=lnms&tbm=isch&sa=X&ei=BKcPVIyrIdagugS9oDIDA&sqi=2&ved=0CAYQ_AUoAQ#facrc=_&imgdii=_&imgrc=Xcfz1bfXsmOqpM%253A%3BJk1HC25GWAlWCM%3Bhttp%253A%252F%252Fwww.electronicstutorials.ws%252Fsequential%252Fseq11.gif%3Bhttp%253A%252F%252Fwww.electronics-tutorials.ws%252Fsequential%252Fseq_3.html%3B392%3B169

https://www.google.com.ph/searchq=astable+output&biw=1366&bih=677&source=lnms&tbm=isch&sa=X&ei=BKcPVIyrIdagugS9oDIDA&sqi=2&ved=0CAYQ_AUoAQ#tbm=isch&q=cmos+gate+of+astable&facrc=_&imgdii=_&imgrc=FGIPeRTnnU2TsM%253A%3Bl0u09NI7ybo5PM%3Bhttps%253A%252F%252Fwww.calvin.edu%252F~pribeiro%252Fcourses%252Fengr332%252FHandouts%252FChap13_files%252Fslide0022_image066.jpg%3Bhttps%253A%252F%252Fwww.calvin.edu%252F~pribeiro%252Fcourses%252Fengr332%252FHandouts%252FChap13_files%252Fslide0022.htm%3B258%3B104

https://www.google.com.ph/searchq=astable+output&biw=1366&bih=677&source=lnms&tbm=isch&sa=X&ei=BKcPVIyrIdagugS9oDIDA&sqi=2&ved=0CAYQ_AUoAQ#tbm=isch&q=555+timer+png&facrc=_&imgdii=_&imgrc=yqTm6CtckSCXMM%253A%3B7ugZdBO-hB5hPM%3Bhttp%253A%252F%252Fupload.wikimedia.org%252Fwikipedia%252Fcommons%252Fthumb%252Fc%252Fc7%252F555_Pinout.svg%252F500px-555_Pinout.svg.png%3Bhttp%253A%252F%252Fwww.newprojectwala.com%252F2013%252F02%252F555-timer-ic.html%3B500%3B330

https://www.google.com.ph/searchq=astable+output&biw=1366&bih=677&source=lnms&tbm=isch&sa=X&ei=BKcPVIyrIdagugS9oDIDA&sqi=2&ved=0CAYQ_AUoAQ#tbm=isch&q=astable+multivibrator&facrc=_&imgdii=_&imgrc=RBgNuB69QvoU5M%253A%3Bk__NDhDuWBcXCM%3Bhttp%253A%252F%252Fwww.yashplus.com%252Fwpcontent%252Fuploads%252F2014%252F01%252Fimage4.png%3Bhttp%253A%252F%252Fwww.yashplus.com%252F2014%252F01%252Fic-555-as-astable-multivibrator%252F%3B761%3B298

Basic Logic Gates

Logic gates are the basic building blocks in digital electronics. They are intended to implement different logic functions such as the NOT, OR, NOR, AND, NAND, XOR and ENOR or XNOR.

There are many ways of describing the function of logic gates and other logic devices. The two most common are through truth tables and timing diagrams. A truth table is a tabulated list of all possible input and output combinations of a logic device. The timing diagram is similar to the truth table in that it shows the outputs for the different possible inputs. The inputs and outputs are vertically aligned and the horizontal spacing denotes changes with respect to time in periods or cycles.

Inverter/ NOT Gate

          -is one of the most popular logic gates in terms of use. It has one input and one output.

x	z
0	1
1	0

OR Gate

          -provides a high or “1” output when at least one of its inputs is “1”. The output is low or “0” when all its inputs are “0”.

x1	x0	z
0	0	0
0	1	1
1	0	1
1	1	1

NOR Gate

          -is formed by an OR gate followed by an inverter.

x1	x0	z
0	0	1
0	1	0
1	0	0
1	1	0

AND Gate

          -is another basic logic gate whose output is a high logic output only when all inputs are high.

x1	x0	z
0	0	0
0	1	0
1	0	0
1	1	1

NAND Gate

          -produces a low logic output only when all its inputs are high.

x1	x0	z
0	0	1
0	1	1
1	0	1
1	1	0

XOR Gate

          -is an "exclusive" gate that produces a high logic output only when one but not all inputs is high.

x1	x0	z
0	0	0
0	1	1
1	0	1
1	1	0

Exclusive NOR Gate

          -is the complement of the exclusive OR gate. It produces a low logic output only when one but not all its inputs is high.

x1	x0	z
0	0	0
0	1	1
1	0	1
1	1	0

References:

          Benjo Tirol. Fundamentals of Digital Electronics. Electronics Hobbyists Publishing House.

          http://www.cs.umd.edu/class/sum2003/cmsc311/Notes/Comb/gates.html
